[ FLIPSCREEN SCREENING BUCKETS ]
FlipScreen's BL95 is a powerful screening bucket for telehandlers 8–12T, delivering precision and speed for a wide range of materials.
Built for your worksite.
The FlipScreen BL95 combines substantial screening capacity with the versatility of loaders, backhoes, large telehandlers and large tractors equipped with suitable auxiliary hydraulics. It brings the screening process directly to the material, whether that material is sitting in a civil stockpile, beside an excavation or spread across a large rural property.
The BL95 can process soil, clay, sand, gravel, aggregate, road base, compost, manure, biomass and mixed excavation spoil. Each carrier brings a different strength—from excavation and backfilling to high-reach loading and long-distance mobility—making the BL96 adaptable across construction, agriculture, recycling and bulk-material handling.
More carrier capability. More recovered material. More work completed on-site.
Product videos
Technical Specifications
Confirm carrier compatibility, hydraulic requirements and final specifications with our team before ordering.
Minimum static tipping load
5,314 kg / 11,715 lb (sheet basis: 1.6 t/m³)
Bucket opening
2130 x 560 mm / 84 x 22 in
Scoop size
0.80 m³ / 1.0 yd³
Total volume
2.40 m³ / 3.0 yd³
Weight
1,165 kg / 2,568 lb
Dimensions (L × W × H)
170 cm / 67 in
251 cm / 99 in
138 cm / 54 in
Hydraulic flow
85 L/min / 18.7 US gal/min
Hydraulic pressure
120 bar / 1740 psi
Inlet & outlet thread
1-3/16"-12 ORFS Male
Case drain thread
N/A
Screen area
4.6 m² / 49.5 ft²
Carrier size
8-12 t / 8.8-12.1 US tons
Tell us about your machine and the material you want to screen. Our team will help confirm the right setup for your application.
Not sure if this is the right model for your machine?
Take the guesswork out of choosing. Use the FlipScreen Product Selector to explore screening buckets matched to your machine, material and application.
